| Category |
Details |
| Model |
AS-ECO-8KW |
| Phase |
1-phase in / 1-phase out |
| PV Input (DC) |
|
| Maximum PV Input Power |
13500W |
| Maximum DC Voltage |
500VDC |
| Start-up Voltage / Initial Feeding Voltage |
90Vdc/120Vdc |
| MPPT Voltage Range |
50Vdc-450Vdc |
| Number of MPPT Trackers / Max Input Current |
2 / 18A+36A |
| Grid Output (AC) |
|
| Nominal Output Voltage |
220/230/240VAC |
| Output Voltage Range |
184-264.5VAC or 195.5-253VAC or 184-264.4VAC (Selectable) |
| Nominal Output Current |
34.8A |
| Power Factor |
>0.99 |
| Maximum Conversion Efficiency (DC/AC) |
97% |
| Off-grid Operation (AC Input) |
|
| AC Start-up Voltage / Auto Restart Voltage |
120-140VAC/180VAC |
| Acceptable Input Voltage Range |
90-280VAC or 170-280VAC |
| Frequency |
50Hz/60Hz (Auto sensing) |
| Maximum AC Input Current |
50A |
| Battery Mode Output (AC) |
|
| Nominal Output Voltage |
220/230/240VAC |
| Output Waveform |
Pure sine wave |
| Efficiency (DC to AC) |
93% |
| Battery & Charger |
|
| Nominal DC Voltage |
48VDC |
| Maximum Solar Charging Current |
190A |
| Maximum AC Charging Current |
190A |
| Maximum Charging Current |
190A |
| General (Physical) |
|
| Dimensions (D×W×H, mm) |
600×483×260 |
| Net Weight (kg) |
38 |
| Interface |
|
| Parallel Function |
Yes, 6 units |
| Communication Port |
RS232/RS485/CAN/Wi-Fi/Dry contact |
| Environment |
|
| Humidity |
5% to 95% Relative Humidity (Non-condensing) |
| IP Degree |
IP65 |
| Operating Temperature |
-10°C ~ 50°C |
| Storage Temperature |
-15°C ~ 60°C |
