Description
The SMART-48100 sets the benchmark for 5kWh home batteries. Sharing the compact form factor (485*475*182mm) of its sibling, this 51.2V system is the ideal building block for modern homes. It balances substantial daily capacity with the intelligence of a touchscreen interface and the flexibility of modular expansion.
Core Advantages for Homeowners:
-
Optimized for Daily Use: With a recommended 50A charge current and 100A max output, it is perfectly sized for smoothing daily solar consumption and providing essential backup power.
-
User-Centric Control: Monitor state of charge, power flow, and system health with ease through the front-facing touchscreen. Side-access wiring keeps connections tidy and accessible.
-
All-Weather Resilience: Engineered to perform from -20°C to 60°C, offering peace of mind in garage, basement, or outdoor shelter installations (within IP43 limits).
-
Future-Proof Foundation: Start with one SMART-48100 and seamlessly add more units in parallel to create a 10kWh, 15kWh, or larger system as your needs evolve.
Technical Specifications:
-
Model: SMART-48100
-
Rated Energy: 5.12 kWh
-
Nominal Voltage: 51.2V
-
Max Continuous Current (Charge/Discharge): 100A
-
Cycle Life: >6,000 cycles @ 80% DoD
-
Dimensions (HWD): 485 * 475 * 182 mm
-
Weight: ~45 kg
-
Communication: RS232, RS485, CAN
-
Protection Rating: IP43
-
Warranty: 5 Years
