| Electrical Characteristics | Nominal Voltage | 12.8V | |||||
| Nominal Capacity | 300 Ah | ||||||
| Energy | 3840 Wh | ||||||
| Cycle Life | ≥6000 Cycles @0.5C | ||||||
| Cell | Model | GSP71173204F | |||||
| Capacity | 300AH | ||||||
| Rated Voltage | 3.2V | ||||||
| Combination Method | 4S1P | ||||||
| Standard Charge | Charge Voltage | 14.4V士0.2V | |||||
| Charge Mode | 0.5C to 14.4V,then 14.4V,charge current to 0.02C(CC/Cv) | ||||||
| Charge Current | 150A | ||||||
| Max. Charge Current | 150A | ||||||
| Standard Discharge | Max. Continuous Current | 150A | |||||
| Discharge Cut-off Voltage | 10V | ||||||
| Environmental | Charge Temperature | 0℃ to 55 ℃(32F to 113F)@60士25% Relative Humidity | |||||
| Discharge Temperature | -20 ℃ to 55 ℃ (-4F to 140F) @60士25% Relative Humidity | ||||||
| Storage Temperature | 0 ℃ to 40 ℃(32F to 104F)@60+25%Relative Humidity | ||||||
| Water Dust Resistance | Ip65 | ||||||
| Mechanical | Plastic Case | ABS | |||||
| Dimensions(mm) | 379*218*262mm | ||||||
| Weight(kg) | 26KG | ||||||
