| Model |
AS-HC100K-215KWH |
| Battery Parameters |
| Battery Chemistry |
LiFePO4 |
| Total Capacity |
215KWH |
| Nominal Capacity |
280AH |
| Nominal Voltage |
768V |
| Operating Voltage Range |
650V-864V |
| Max Charging Current |
140A |
| Max Discharge Current |
140A |
| Storage Temperature Range |
‘-20℃-45℃ |
| Operating Temperature Range |
‘-20℃-60℃ |
| Operating RH |
10%-90% |
| Storage and Transportation RH |
5%-95% |
| Working Altitude |
≤3000m |
| Communication Type |
CAN/RS485 |
| Dimension |
1460*1400*2203mm |
| Net Weight |
≈2500kg |
| Cooling Mode |
Liquid Cooling |
| PCS Parameters |
| Rated Output Power |
105KW |
| Max AC Current |
167A |
| Max DC Power |
126KW(1Min) |
| Rated Operating Voltage |
230/400VAC |
| Approved Grid Freqvency Range |
50Hz±5Hz |
| AC Hamonic Voltage |
＜3% (Linear load) |
| Voltage Deviation |
＜5% (Linear load) (Phase)＜3 |
